SMC | Assembled Roving for SMC Applications

SMC | Assembled Roving for

SMC Applications

PRODUCT FEATURES

. Boron-free ECR-Glass
. Environment friendly
. Good unwinding
. Good choppability & dispersion
. Low fuzz & static
. High mechanical properties
. Suitable for multi purpose SMC

PRODUCT
SPECIFICATION SMC-H SMC-M

. Glass Type ECR (B-Free) ECR (B-Free)
. Filament Diameter (µ) Nom. 14 Nom. 14
. Roving Tex (g/10³m) ± % 5 2400-4800 2400-4800
. Split Tex (g/10³m) Nom. 80 Nom. 80
. Moisture Content (%) Max. 0,15 Max. 0,15
. Sizing Type Silane Silane
. Loss of Ignition (%) 1,25 ±0,2 1,25 ±0,2
Polyester, Polyester,
. Compatability
Vinylester Vinylester
. Solubility In Styrene High Medium

PACKAGING

Pallet Bobbins Layers Pallet Product Net
Type Dimensions (cm) per Pallet per Pallet Height (cm) Weight per Pallet

Bulk packaging 93 x 123 48 4 120 1032

BOBIN DIMENSIONS

Weight (kg) Inner Diameter(mm) Outer Diameter(mm) Height(mm)
Nom. 21,5 75 295 255

STORAGE
Products should be stored in original package in dry and dust free area.
Storage temperature is between 10°C - 30°C at humidity between 50% - 75%.

WARRANTY
All physical & chemical properties represent average values and subject to normal production variations.
The specifications are also subject to change. For current information please contact Beşler Office.

www.beslerglassfiber.com.tr
