- Boron-free ECR-glass
- Environment friendly
- Good unwinding
- Fast wet out
- Good translucency
- Good choppability & dispersion
- Low fuzz & static
| PRODUCT SPECIFICATION |
| Glass Type |
ECR (B-Free) |
| Filament Diameter (μ) |
Nom. 13 |
| Roving Tex (g/10³m) |
2400± % 5 |
| Split Tex (g/10³m) |
Nom. 40 |
| Moisture Content (%) |
Max. 0,1 |
| Sizing Type |
Silane |
| Loss of Ignition (%) |
0,55 ±0,15 |
| Compatability |
Polyester |
| Type |
Pallet Dimensions (cm) |
Bobbins per Pallet |
Layers per Pallet |
Pallet Height (cm) |
Product Net Weight per Pallet |
| Bulk packaging |
93x123 |
48 |
4 |
120 |
1032 |
| Weight(kg) |
Inner Diameter(mm) |
Outer Diameter(mm) |
Height(mm) |
| Nom. 21,5 |
75 |
295 |
255 |
Products should be stored in original package in dry and dust free area. Storage temperature is between 10°C - 30°C at humidity between 50% - 75%. Pallets must be single stacked.
All physical & chemical properties represent average values and subject to normal production variations. The specifications are also subject to change. For current information please contact Beşler Office.
