CR | Assembled Roving for Pipe-Chopping Application

CR | Assembled Roving for TS | Assembled Roving for Translucent Sheet

Pipe-Chopping Application
Weaving Stitching

PRODUCT FEATURES PRODUCT FEATURES

. Boron-free ECR-glass . Boron-free ECR-Glass
. Environment friendly . Environment friendly
. Good unwinding . Good unwinding
. Good wet out . Fast wet out TS | Assembled Roving for Translucent Sheet - Weaving Stitching
. Good choppability . Good translucency
. Low fuzz & static . Good choppability & dispersion
. Low fuzz & static
PRODUCT
SPECIFICATION CR PRODUCT
SPECIFICATION
. Glass Type ECR (B-Free) . Glass Type ECR (B-Free)
. Filament Diameter (µ) Nom. 13 . Filament Diameter (µ) Nom. 13
. Roving Tex (g/10³m) 2400 ± % 5 . Roving Tex (g/10³m) 2400 ± % 5
. Split Tex (g/10³m) Nom. 57 . Split Tex (g/10³m) Nom. 33
. Moisture Content (%) Max. 0,1 . Moisture Content (%) Max. 0,1
. Sizing Type Silane . Sizing Type Silane
. Loss of Ignition (%) 1,15 ±0,15 . Loss of Ignition (%) 0,55±0,15
. Compatability Polyester, Vinylester . Compatability Polyester

PACKAGING PACKAGING

Pallet Bobbins Layers Pallet Product Net Pallet Bobbins Layers Pallet Product Net
Type Dimensions (cm) per Pallet per Pallet Height (cm) Weight per Pallet Type Dimensions (cm) per Pallet per Pallet Height (cm) Weight per Pallet
Bulk packaging 93 x 123 48 4 120 1032 Bulk packaging 93 x 123 48 4 120 1032

BOBIN DIMENSIONS BOBIN DIMENSIONS

Weight (kg) Inner Diameter(mm) Outer Diameter(mm) Height(mm) Weight (kg) Inner Diameter(mm) Outer Diameter(mm) Height(mm)
Nom. 21,5 75 295 255 Nom. 21,5 75 295 255

STORAGE STORAGE
Products should be stored in original package in dry and dust free area. Products should be stored in original package in dry and dust free area.
Storage temperature is between 10°C - 30°C at humidity between 50% - 75%. Storage temperature is between 10°C - 30°C at humidity between 50% - 75%.

WARRANTY WARRANTY
All physical & chemical properties represent average values and subject to normal production variations. All physical & chemical properties represent average values and subject to normal production variations.
The specifications are also subject to change. For current information please contact Beşler Office. The specifications are also subject to change. For current information please contact Beşler Office.

www.beslerglassfiber.com.tr www.beslerglassfiber.com.tr
